Electronics Module (Sheet 1 of 3)
Chapter 5: Parts List
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 5 - 25
Service Manual (MAN272 REV 4)
5
Table 5-7. Electronics Module (Sheet 1 of 3)
Item Number Part Number Quantity Description
1 6342201
or
6342202
or
6342203
or
6342204
or
6342205
or
6342206
1 Power cord, detachable 110V
or
Power cord, detachable 220V,
Australia/New Zealand
or
Power cord, Continental Europe
or
Power cord, UK/Ireland
or
Power cord, Switzerland
or
Power cord, Denmark
2 46015 2 Screw, bottom rail end cap
3 64002 1 Power entry module
4 4314317
or
4360519
2 Fuse, timelag, 4A, 125V AC
or
Fuse, timelag, 2A, 250V AC
5 66230 1 Cable assembly, ground
6 43878 18 Screw, button hd Torx®
7 4142501S 1 Cable assembly, pendant control
8 6398848 1 Bottom cover weldment
9 63166 2 Screw, button hd Torx®
10 66129 1 Night light and cable assembly
6679903 1 Assembly, lens, bulb and holder
4734501 1 Bulb
11 4142301S 1 Cable assembly, Trendelenburg
mechanical limits
12 19124 2 Cable tie
13 6395948 1 Electronic plate weldment
14 35663 5 Standoff, P.C. board
15 4840501 2 Battery, lead acid, sealed, 12V, 7.2A
16 6583048 1 Bracket, battery hold-down
17 63945 1 Cable assembly, battery
