Electrical Cable Routing (Sheet 1 of 2)
Chapter 5: Parts List
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 5 - 31
Service Manual (MAN272 REV 4)
5
Table 5-10. Electrical Cable Routing (Sheet 1 of 2)
Item Number Part Number Quantity Description
1 64002 1 Power entry module
2 66129 1 Night light and cable assembly
3 4142301S 1 Trendelenburg mechanical limits cable
assembly
4 43878 2 Screw, button hd Torx®
5 19124 5 Cable tie
6 4142501S 1 Cable assembly, pendant control
7 63981 1 Switch, lockout
8 44279 1 Night light sensor and cable assembly
9 63960 1 Transformer assembly
10 66278 1 Transformer assembly, OB light option
11 17292 2 Cable clamp
12 63944 1 Cable assembly, lockout
