Sleep Deck Module (Sheet 1 of 3)
Chapter 5: Parts List
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 5 - 35
Service Manual (MAN272 REV 4)
5
Table 5-12. Sleep Deck Module (Sheet 1 of 3)
Item Number Part Number Quantity Description
1 41059 1 Panel, V seat
2 40958 2 Snap, mattress retaining
35308 2 Finish washer
3 41060 1 Panel, U seat
4 777 2 Hex locknut
5 41047 4 Washer, nylon
6 43552 2 Ring, retaining
7 40817 2 Ring, retaining
8 6392148 1 Seat section weldment
9 659660148 1 Labor grip weldment, lh
10 430220263 2 Foam tube, ¾" ID x 25"
11 4116363 2 Trendelenburg handle plug
12 6394801PL 1 Labor grip release weldment, lh
13 42617 2 Washer, spring
14 9033810 2 Screw, shoulder
15 62919 2 Cap, release handle, vinyl dipped
16 6314306PL 1 Clevis pin
17 61615 2 Rue ring cotter
18 61653PL 1 Clevis pin
19 9026307 2 Bearing, DU self-lube
20 9026006 2 Screw, shoulder
21 4127048 1 Front shroud, U seat
22 4127148 1 Front shroud, V seat
23 43878 4 Screw, button hd Torx®
24 6394802PL 1 Labor grip release weldment, rh
25 40812 2 Spring
26 40811 2 Pin, locking
27 36958 As required Lubricant
28 65967 2 Clevis pin
29 49257 2 Hairpin
To Next Page
