Calf Support Module—P3700A
Chapter 5: Parts List
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 5 - 55
Service Manual (MAN272 REV 4)
5
Table 5-20. Calf Support Module—P3700A
Item Number Part Number Quantity Description
1 68117 2 Knob assembly, calf support
2 37145 2 Lock stud
3 37146 4 Knob stud
4 8651 As required Loctite® #262
5 3714463 4 Knob
6 66975 2 Threaded insert
7 38677 2 Roll pin
8 67258 2 Ring, retaining, internal
9 6446601 2 Screw, Torx®
10 66979 2 Pin, calf support
11 6696801 1 Mount, calf support, lh
12 66966 2 Set screw, cup point
13 67260 2 Set screw cup point
14 66971 2 Key, calf support
SA1736 2 Key kit
15 67259 2 Spring
16 6697301 1 Pull handle, lh
17 6696701 1 Arm, calf support, lh
18 47598 2 Ball and rod
19 23261 2 Roll pin
20 70742 2 Bracket, calf support
21 19918 4 Washer
22 19224 4 Bolt
23 4126048 2 Former, calf support
24 67247 2 Cover
25 6697302 1 Pull handle, rh
26 6696802 1 Mount, calf support, rh
27 6696702 1 Arm, calf support, rh
To Next Page
