Base Module—P3700B/C (Sheet 1 of 2)
Chapter 5: Parts List
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 5 - 61
Service Manual (MAN272 REV 4)
5
Table 5-24. Base Module—P3700B/C (Sheet 1 of 2)
Item Number Part Number Quantity Description
1 152317 2 Top, orange pedal
2 70731 2 Top, green pedal
3 70780 2 Bottom, orange pedal
4 152316 2 Bottom, green pedal
5 142634 1 Brake link, foot, rh
6 152893 2 Pedal weldment
7 142628 2 Brake cam
8 43951 4 Pin
9 142639 2 Flanged bushing
10 143966 2 Brake pedal support
11 434602 1 End cap cross tube, rh
12 142635 2 Brake link, head
13 41308 4 End cap
14 90477 4 Shoulder bolt
15 4708501 4 Base boss cap
16 9026312 4 DU bushing
17 44352 6 Cotter pin
18 757 4 Clevis pin
19 43878 16 Screw
20 4126948 4 Leg cover
21 158890 8 Retaining ring
22 41002 8 Spacer, rocker arm
23 32425 4 Bolt
24 34715 4 Rover arm
25 41001 4 Groove pin, rocker arm
26 32572 4 Screw
27 43030 4 Washer
28 40980301 4 Washer
29 142633 1 Brake link, foot, lh
30 4394601 1 End cap cross tube, lh
31 43957 1 Detent housing place
32 142638 1 Spring
33 40827 2 Double sided tape
