Foot Support Module—P3700B/C
Chapter 5: Parts List
Page 5 - 72 Affinity® Three Birthing Bed and Affinity® Four Birthing Bed
Service Manual (MAN272 REV 4)
32 143010 1 Bellows, foot support, rh
33 143225 1 Release handle weldment, rh
34 6696502 1 Mechlok®, foot tilt, rh
35 145103 1 Kit, bellows assembly, rh (includes 4, 20,
and 32)
36 145104 1 Kit, bellows assembly, lh (includes 4, 20,
and 26)
Not shown 155065S 1 Heel cup kit
Not shown 163716S 1 Heel cup and handle kit
Not shown 163717S 1 Heel cup and bellows kit, rh
Not shown 163718S 1 Heel cup and bellow kit, lh
Item Number Part Number Quantity Description
