Calf Support Module—P3700B/C/D
Chapter 5: Parts List
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 5 - 75
Service Manual (MAN272 REV 4)
5
Table 5-28. Calf Support Module—P3700B/C/D
Item Number Part Number Quantity Description
1 146628 1 Calf support pad and arm assembly, rh
2 146683 1 Calf support pad and arm assembly, lh
3 142621 1 Calf support arm assembly, rh
4 142620 1 Calf support arm assembly, lh
5 142388 2 Calf support pad
6 142619 1 Calf support arm, rh
7 142628 1 Calf support arm, lh
8 58910207000 2 Pin, dowel, 3/16 x 1/2
9 143226 2 Handle grip
10 47598 2 Ball and rod
11 142615 2 Ball seat
12 142616 8 Bellville spring
13 143219 2 Shim
14 166488 2 Cam follower
15 142612 2 Cam lobe
16 142613 2 Cam base
17 67258 2 Internal retaining ring, 1-5/16
18 70537 2 Pin, calf support
19 142 2 Pin, roll
20 142397 2 Calf support key
21 9029104 2 Setscrew, 8-32, 1/4, cup
22 67259 2 Spring
23 14419 1 Latch handle, rh
24 14418 1 Latch handle, lh
25 6798002 1 Mount, calf arm, rh
26 6798001 1 Mount, calf arm, lh
27 69391 2 Screw (short)
28 138735 2 Screw (long)
29 3517 2 Roll pin
Not show 167970S 1 Calf support kit
Not shown SA3351 1 Grease, litium, tube
