Sleep Deck Module—P3700D
Chapter 5: Parts List
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 5 - 109
Service Manual (MAN272 REV 4)
5
Table 5-39. Sleep Deck Module—P3700D
Item Number Part Number Quantity Description
1 65986 13 Screw
2 41061 1 Head deck
3 41344 2 Bumper plug
4 67088 2 Slide
5 6393901PL 1 Handle weldment, CPR, lh
6 6393801 1 CPR handle, lh
7 35326 2 E-ring
8 9033907 4 Screw, locking
9 64007 2 Release cable assembly
10 65912 1 Damper, CPR assist
11 64012 1 Gas spring, CPR assist
12 61440 1 Washer
13 44352 1 Hairpin
14 40827 As required Dual-sided adhesive tape
15 19124 3 Cable tie
16 6394348 1 Bracket, CPR cable attachment
17 6395348 1 Bracket, CPR cable housing
18 6393802 1 CPR handle, rh
19 6393902PL 1 Handle weldment, CPR, rh
20 165220 1 Head section weldment
21 4106848 1 Splash channel
To Next Page
