7.3 Telescoping Calf Supports (P35745A) or Telescoping Full Leg Supports (P7634C)
Chapter 7: Accessories
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 7 - 7
Service Manual (MAN272 REV 4)
7
Adjustment
1. Loosen the swivel clamp screws (C) to enable the cradles (D) to be
swiveled to the desired direction.
2. Tighten the swivel clamp screws (C) to secure the cradles (D) in the desired
position.
Insufficient tightening will allow the cradles to slip and lose their original
position. Personal injury could occur.
The supports are intended to be used in the prescribed manner only.
Failure to use this product as outlined may result in personal injury or
equipment damage.
Removal
To remove the telescoping supports, reverse the installation procedure.
