3.7 Using D/A Output
93
For integrated value (Ah+, Ah-, Ah, Wh+, Wh-, or Wh)
3 Press or until the parameter
flashes.
4 Press or to select the
parameter you wish to output.
If you select integrated value, the current range will
be shown in display area d.
5 Press or until the output f.s.
flashes.
6 Press or to select the out-
put f.s..
Example: For Wh and AC+DC
Default setting: 5 k
Settings: 5 k → 50 k → 500 k → 5 M → 50 M →
500 M → 5000 M → 5 m → 50 m →
500 m → 5 → 50 → 500 → 5 k ⋅⋅⋅
7 Press or until the current
range flashes.
8 Press or to select the cur-
rent range you wish to output.
Default setting: totAL
Settings:
totAL → 200 mA → 500 mA → 1 A →
2 A → 5 A → 10 A → 20 A → b →
totAL ⋅⋅⋅
9 Press to exit the settings.
The instrument will return to the normal display
(Measurement screen).
