1-62
OPERATOR'S STATION
5. Push selector knob (2) to display Sub Meter Selection
screen (7).
6. Rotate selector knob (2) to highlight Desired Sub Meter
(8). (Selecting OFF will not display a sub meter.)
7. Push selector knob (2) to enable the changes.
f
NOTE:
 Only one sub meter can be selected at a time.
 When a display is selected, the mark "" is displayed in
green. When not selected, the mark "" is displayed in gray.
7
8
2
MDAA-01-165EN
MDCD-01-026
