7-84
MAINTENANCE
Replace Fuel Main Filter Element
--- every 1000 hours or when fuel filter restriction
alarm is lit
IMPORTANT:
Be sure to use only genuine Hitachi elements for
the fuel main filter element and the pre-filter
element. Failure to do so may deteriorate the engine
performance and/or shorten the engine service life.
Please be noted that all engine failures caused by
using other manufacturers' elements are excluded
from Hitachi Warranty Policy.
Take care not to allow dirt and/or water to enter the
fuel tank.
Procedures:
1. Close cock (1) on the bottom of the fuel tank.
(to next page)
Closed Position
Main Filter
Main Filter
ZX160-6 class
MDC1-07-072
ZX300-6, 330-6 class
Main Filter
MDC1-07-084
ZX200-6, 240-6 class
MDC1-07-083
Main Filter
MDC1-07-020
1
ZX120-6 class
MDC1-07-104
