Hitachi ZAXIS 120-6 class - Greasing; Front Joint Pins

To Next Page

To Previous Page

7-30

MAINTENANCE

A. Greasing

Front Joint Pins

--- every 500 hours (first time after 250 hours)

Lubricate all fittings shown in the figure.

 Boom Cylinder Bottom Side

 Boom Foot

M178-07-007

M157-07-156

M157-07-155
