Hitachi ZAXIS 120-6 class User Manual

1-112
OPERATOR'S STATION
Name of Components
1- Front Vent
2- Foot Vent
3- Defroster Vent
4- Rear Vent
5- Temperature Control Switch/Mode Switch
6- AUTO/OFF Switch/Fan Switch
f
NOTE: Air flow direction can be adjusted by moving the
louvers on all air vents except for foot vent (2). The louvers
on front vents (1) and defroster vent (3) can be completely
opened and closed by hand.
MDAA-01-289
4
1
3 2
5
6
MDAA-01-295
MDCD-01-026
