12-4
SPECIFICATIONS
Bucket Types and Applications
ZX130-6
Bucket
Bucket Capacity
m
3
Bucket Width
mm
PCSA
(Heaped)
CECE
(Heaped)
With Side
Cutters
Without Side
Cutters
2.52 m
Arm
3.01 m
Arm
2.52 m
Arm
and extension
Hoe Bucket
0.19 0.17 570 450
0.30 0.25 700 580
0.40 0.33 840 720
0.45 0.40 920 800
0.50 0.45 1010 890
* -
0.59 0.50 1070 950
- -
0.66 0.55 - 1030 - - -
Reinforced Hoe Bucket 0.50 0.45 1010 890
* -
Reinforced Hoe Bucket 0.59 0.50 1070 950
- -
One Point Ripper - - -
- -
Slope-Finishing Blade - 1000 x 1600
-
V-Type Bucket -
-
Clamshell Bucket
(Center-pull type)
0.30 - 560
- -
Clamshell Bucket
(Shell-push type)
0.40 - 590
- -
f
NOTE:
Symbols in the above table have the following meanings.
: General excavating
: Light duty excavating
: Rock digging
: Loading work
: Slope-finishing work
- : Not applicable (not warrantable)
Hoe bucket is applicable to the following types of work.
General excavating:
For digging and loading operation of sand, gravel, clay, ordinary earth and so on.
Light duty excavating:
For digging and loading operation of dry, loosened earth, sand, mud and so on.
Their bulk density shall be less than 1.60 t/m
3
as a standard.
Loading:
For loading operation of dry, loosened earth and sand.
Their bulk density shall be less than 1.10 t/m
3
as a standard.
Rock digging:
For digging/loading operation of mountain gravels, blasted rock, hard clay, soft rock and so on.
* Applicable only to 700 mm grouser shoe.
IMPORTANT: Using inapplicable buckets may cause serious damage to the front structure such as boom, arm and
hydraulic cylinders.
45 ˚
