12-7
SPECIFICATIONS
Shoe Types and Applications
ZX160LC-6
Shoe Width 500 mm Grouser Shoe
600 mm Grouser Shoe 700 mm Grouser Shoe
Application
For Ordinary Ground
(Standard)
For Weak Footing
(Option)
For Weak Footing
(Option)
Operating Weight kg
17200 17500 17700
Base Machine Weight kg
13700 13900 14200
Counterweight
Weight
kg
3200 3200 3200
Cab Height mm
**3030 **3030 **3030
Minimum Ground
Clearance
mm
*470 *470 *470
Undercarriage Length mm
3920 3920 3920
Undercarriage Width mm
2500 2590 2690
Ground Pressure
50 kPa
(0.51 kgf/cm
2
)
42 kPa
(0.43 kgf/cm
2
)
36 kPa
(0.37 kgf/cm
2
)
f
NOTE:
The specifications for the front-end attachment is for 2.58 m arm with PCSA 0.60 m
3
reinforced bucket (heaped).
Other than 500 mm grouser shoe should not be used on gravel or rocky ground. Operating or digging on gravel ground
may cause serious damage to shoe, shoe bolts and other parts such as rollers.
*The dimensions do not include the height of the shoe lug.
**The dimensions include the height of the handrail on cab.
