12-23
SPECIFICATIONS
Shoe Types and Applications
ZX350LC-6
Shoe Width
600 mm
Grouser Shoe
700 mm
Grouser Shoe
800 mm
Grouser Shoe
Application
For Ordinary Ground
(Standard)
For Weak Footing
(Option)
For Weak Footing
(Option)
Operating Weight kg 35000 35600 36000
Base Machine Weight kg 26900 27500 27900
Counterweight Weight kg 7600 7600 7600
Cab Height mm 3150 3150 3150
Minimum Ground
Clearance
mm * 500 * 500 * 500
Undercarriage Length mm 4950 4950 4950
Undercarriage Width mm 3190 3290 3390
Ground Pressure
66 kPa
(0.67 kgf/cm
2
)
57 kPa
(0.58 kgf/cm
2
)
51 kPa
(0.52 kgf/cm
2
)
f
NOTE:
The Specifications for the front-end attachment is for 3.2 m arm with PCSA 1.4 m
3
bucket.
700, 800 mm grouser shoe and 900 mm triangular shoe should not be used on gravel or rocky ground.
 * The dimensions do not include the height of the shoe lug.
