7-57

MAINTENANCE

Sampling the Engine Oil

NOTE: The line is equipped with a valve (10) for sampling

the engine oil. The valve has a cap (9). For instructions on

sampling the engine oil, consult your authorized dealer.

MDC1-07-112
