7-53
MAINTENANCE
B. Engine
Check Engine Oil Level
---daily
1. Confirm that pilot control shut-off lever (1) is in the LOCK
position.
2. Confirm that all control levers are placed in neutral.
3. Insert key (2) into the key switch. Turn it to ON position.
Press and hold switch (3) with the engine stopped.
The engine oil level indicator (4) must be displayed in
green.
IMPORTANT: Do not rely only on the monitor display for
checking the machine conditions; visually check them
yourself as required such as oil level.
Always check the machine on a firm, level surface.
f
NOTE: If the security function is enabled, a password is
required.
2
1
LOCK position
MDAA-01-295
4
MDC1-01-502
MDC1-01-041
3
MDCD-01-026
To Next Page
