OPERATOR'S STATION
Switch Panel
f
NOTE: The optional switch locations differ, depending on the
kinds of optional devices that the machine is equipped with.
Before using the switches, confirm which types of optional
devices the machine is equipped with. Raise the armrest when
operating the optional switch. All available optional devices
are shown below.
 Rear Light Switch
 Perimeter Lights Switch
 Travel Alarm Deactivation Switch
 Seat Heater Switch
 Electrical Control Main Switch
Optional Switch
Location
Armrest
MDAA-01-327
