12-11
SPECIFICATIONS
Shoe Types and Applications
ZX210LC-6
Shoe Width
600 mm
Grouser Shoe
700 mm
Grouser Shoe
800 mm
Grouser Shoe
Application
For Ordinary Ground
(Standard)
For Weak Footing
(Option)
For Weak Footing
(Option)
Operating Weight kg
22100 22500 22800
Base Machine Weight kg
17500 17900 18200
Counterweight Weight kg
4850 4850 4850
Cab Height mm
2950 2950 2950
Minimum Ground
Clearance
mm
*450 *450 *450
Undercarriage Length mm
4460 4460 4460
Undercarriage Width mm
2990 3090 3190
Ground Pressure
46 kPa
(0.47 kgf/cm
2
)
40 kPa
(0.41 kgf/cm
2
)
35 kPa
(0.36 kgf/cm
2
)
f
NOTE:
The specifications for the front-end attachment is for 2.91 m arm with PCSA 0.80 m
3
bucket.
700 mm and 800 mm grouser shoe should not be used on gravel or rocky ground.
* The dimensions do not include the height of the shoe lug.
