13-13
BLADE
OPTIONAL ATTACHMENTS AND DEVICES
Shoe Types and Applications
ZX130-6 with Blade
Shoe Width
500 mm
Grouser Shoe
600 mm
Grouser Shoe
700 mm
Grouser Shoe
Application
For Ordinary Ground
(Standard)
For Weak Footing
(Option)
For Weak Footing
(Option)
Operating Weight kg
14300 14600 14800
Base Machine Weight kg
10600 10900 11100
Counterweight Weight kg
2550 2550 2550
Cab Height mm
**2870 **2870 **2870
Minimum Ground
Clearance
mm
*410 *410 *410
Undercarriage Length mm
3580 3580 3580
Undercarriage Width mm
2490 2590 2690
Ground Pressure
45 kPa
(0.46 kgf/cm
2
)
38 kPa
(0.39 kgf/cm
2
)
33 kPa
(0.34 kgf/cm
2
)
f
NOTE:
The specifications for the front-end attachment are for a 2.52 m arm with PCSA 0.50 m
3
standard bucket.
600 mm, 700 mm, 800 mm grouser shoe and 500 mm pad crawler shoe should not be used on gravel or rocky ground.
* The dimensions do not include the height of the shoe lug.
** The dimensions include the height of the handrail on cab.
