Hitachi ZAXIS 120-6 class User Manual

7-27
MAINTENANCE
Bucket Parts
Part No. Quantity
Tooth
Tooth 4512365 5
Lock Pin 4512366 5
Lock Rubber 4501625 5
Side Cutter (right side) 2021232 1
Side Cutter (left side) 2021233 1
Side Cutter
Bolt J932275 12
Nut J951022 12
Spring Washer A590922 12
O-ring 4089028 4
f
NOTE: Quantity row on the above table represents number of parts used for one bucket. The parts quantity of O-ring
includes connection part of arm and link.
Optional Parts
Part No. Quantity
One Point Ripper
Tooth 4507888 1
Pin 4507890 1
Bushing Rubber 4507891 1
Ripper Bucket
Tooth 4507888 1
Pin 4507890 1
Bushing Rubber 4507891 1
Tooth 4383048 2
Lock Pin 4383069 2
Rock Bucket
Tooth 4400253 5
Lock Pin 4383465 5
Shroud 4435856 1
Shroud 4435857 1
Bolt J932780 6
Nut J951027 6
Washer 4085857 6
Ditch Cleaning Bucket (0.36
m
3
, 0.40 m
3
, 0.50 m
3
)
Tooth 973347 *
Lock Pin 963229 *
Lock Rubber 963227 *
Reinforced Hoe Bucket HD
Type
Tooth 4512365 5
Lock Pin 4512366 5
Lock Rubber 4501625 5
* 2
Reinforced Hoe Bucket HD
Type (Transverse-Type-Pin)
Tooth 4380343 5
Pin 4380844 5
f
NOTE: * The parts quantity of items with * mark.
Four parts are required per each bucket of 0.36, 0.40, and 0.50 m
3
.
Seven parts are required per one ditch cleaning bucket with teeth.
An item with * 2 mark is for ZX240-6 class.
