7-111
MAINTENANCE
2221
Battery
 Fusible Link (Main Fuse)
 In case the starter will not rotate even if the key switch is
turned to the START position, fusible link may be the cause
of the trouble. Remove the cover next to the battery to
check the fusible link. Replace it if blown.
21- + Side (Red)
45 A
22- – Side (Black)
65 A
M1U1-07-023
