7-153

MAINTENANCE

30. Cab top handrail mounting bolt

31. Front pin-retaining bolt

Boom cylinder bottom pin-retaining bolt

(ZX330-6 class only)

ZX120-6, 160-6 class

MDC1-07-077

MDCS-07-004

MDC1-07-099

M173-07-016
