12-17
SPECIFICATIONS
Specifications
ZX300LC-6
Model ZX300LC-6
Type of Front-End Attachment 3.11 m Arm
Bucket Capacity (Heaped) PCSA 1.25 m
3
, CECE 1.10 m
3
Counterweight Weight 5600 kg
Operating Weight 29800 kg
Base Machine Weight 23500 kg
Engine Type Isuzu AQ-6HK1XASA-02S
Engine Power ISO 14396: 186 kW/1900 min
-1
(253 PS/1900 rpm)
A :
Overall Width (Excluding back mirrors)
3190 mm
B :
Cab Height 3120 mm
C :
Rear End Swing Radius 3250 mm
D :
Minimum Ground Clearance *510 mm
E :
Counterweight Clearance *1130 mm
F :
Engine Cover Height *2840 mm
G :
Overall Width of Upperstructure 2990 mm
H :
Undercarriage Length 4940 mm
I :
Undercarriage Width 3190 mm
J :
Sprocket Center to Idler Center 4050 mm
K :
Track Shoe Width 600 mm (Grouser shoe)
Ground Pressure 56 kPa (0.57 kgf/cm
2
)
Swing Speed 10.3 min
–1
(rpm)
Travel Speed (fast/slow) 5.2/3.1 km/h
Gradeability 35 ° (tanθ = 0.70)
f
NOTE: * The dimensions do not include the height of the shoe lug.
MDC1-12-003
A
G
B
D
K
I
C
F
E
J
H
