Hitachi ZAXIS 120-6 class User Manual

S-44
VISIBILITY MAP
: Operator’s eye point : Masking area
A : 1m Rectangular Boundary (1mRB) : Mirror visibility
B : 12m Visibility Test Circle (VTC) : Camera visibility
: Standard Mirror(s)
: Masking on
1mRB / VTC
: Standard rear view camera
: Standard side view camera
Monitor screen
Visibility Map
Image behind, image on right of machine
B
A
camera
visibility
camera camera
visibilityvisibility
mirror visibilitymirror visibility
MDC1-VM-067
MDC1-VM-040EN
Monitor screen
B
A
camera
visibility
camera camera
visibilityvisibility
camera camera
visibilityvisibility
mirror visibilitymirror visibility
Visibility Map
Image behind, image on right, image on left of machine
MDC1-VM-068
MDC1-VM-041EN
