Hitachi ZAXIS 120-6 class User Manual

S-54
VISIBILITY MAP
MDC1-VM-039
MDC1-VM-040
: Operator’s eye point : Masking area
A : 1m Rectangular Boundary (1mRB) : Mirror visibility
B : 12m Visibility Test Circle (VTC) : Camera visibility
: Standard Mirror(s)
: Masking on
1mRB / VTC
: Standard rear view camera
: Standard side view camera
A
A
B
B
MDC1-VM-051
MDC1-VM-052
Visibility Map
Image around machine
Monitor screen
Monitor screen
Visibility Map
Image behind, image on right of machine
mirror visibility
mirror visibility
camera
visibility
camera
visibility
camera camera
visibilityvisibility
