Hitachi ZAXIS 120-6 class User Manual

S-57
VISIBILITY MAP
MDC1-VM-039
MDC1-VM-040
B
B
A
A
: Operator’s eye point : Masking area
A : 1m Rectangular Boundary (1mRB) : Mirror visibility
B : 12m Visibility Test Circle (VTC) : Camera visibility
: Standard Mirror(s)
: Masking on
1mRB / VTC
: Standard rear view camera
: Standard side view camera
MDC1-VM-045
MDC1-VM-046
Visibility Map
Image around machine
Monitor screen
Monitor screen
Visibility Map
Image behind, image on right of machine
mirror visibility
mirror visibility
mirror visibility
mirror visibility
camera
visibility
camera
visibility
camera camera
visibilityvisibility
