SCANNER SAFETY AND LOCAL CONTROLS
Radiation safety warning icon
Main red and green shutter status indicators
Nuclear sensor keyswitch indicator
Laser eye safety warning icon
Laser sensor keyswitch indicator
Sensors on this row contact the sheet when enabled caution icon
Head split enable caution indicator and icon
Basis weight sensor enable button/indicator
Basis weight shutter open red warning indicator
Ash sensor power on enable button/indicator
Ash shutter open red warning indicator
Laser caliper sensor enable button/indicator
Photo surf sensor enable button/indicator
Contacting caliper sensor enable button/indicator
Porosity sensor enable button/indicator
Extensional stiffness sensor enable button/indicator
