206 Voyager 1602g User Guide
*Storage outside of this temperature range could be detrimental to battery life.
Vibration Withstands 10G peak from 10 to 500 Hz
ESD 12kV air, 8kV direct
Image Size 1040 x 720 pixels
Scan Performance
Pitch, Skew +
60°, +70°
Motion Tolerance: up to 10cm per second for 13 mil UPC
Symbol Contrast Grade 1.0 (20% or greater)
Depth of Field
Typical Performance
5 mil Code 39 24 - 202mm (1.0 -7.9 in.)
13 mil UPC-A 39 - 324mm (1.6 - 12.7 in.)
20 mil Code 39 42 - 511mm (1.7 - 20.01 in.)
6.7 mil PDF417 23 - 177mm (0.9 - 6.9 in.)
10mil Data Matrix 12 - 168mm (0.5 - 6.6 in.)
20mil QR Code 24 - 262mm (1.0 - 10.3 in.)
Guaranteed Performance
5 mil Code 39 32 - 179mm (1.3 - 7.0 in.)
13 mil UPC-A 42 - 281mm (1.7 - 11.0 in.)
20 mil Code 39 46 - 356mm (1.8- 14.0 in.)
6.7 mil PDF417 28 - 155mm (1.1 - 6.1 in.)
10mil Data Matrix 18 - 149mm (0.7 - 5.8 in.)
20mil QR Code 27 - 220mm (1.1 - 8.6 in.)
Parameter (Continued) Specification
