IMPORTANT:IMPORTANT:
The ring terminals must be UL approved and accommodate 12 gauge wires.
IMPORTANT:IMPORTANT:
The minimum nominal thread diameter of a pillar or stud type terminal must be 3.5 mm (0.138 in). The diameter of a
screw type terminal must be 5.0 mm (0.197 in).
2. If the power source requires ring tongues, use a crimping tool to install the ring tongues on the power cord wires.
3. Stack each same-colored pair of wires and then attach them to the same power source. The power cord consists of three wires (black,
red, and green).
For more information, see the documentation that ships with the power supply.
Transceiver optionTransceiver option
Transceivers serve as the connection between the adapter and the network cable for maintaining high-speed performance.
SubtopicsSubtopics
Transceiver warnings and cautionsTransceiver warnings and cautions
Installing a transceiverInstalling a transceiver
Transceiver warnings and cautionsTransceiver warnings and cautions
WARNING:WARNING:
Fiber-optic transceivers and fiber-optic cables connected to transceivers emit laser light that can damage your eyes. To
avoid eye injuries, avoid direct eye exposure to the beam from the fiber-optic transceiver or into the ends of fiber-optic
cables when they are powered-up.
CAUTION:CAUTION:
The presence of dust in transceiver ports can cause poor cable connectivity. To prevent dust from entering, install a dust
plug in an unused transceiver port.
CAUTION:CAUTION:
Supported transceivers can be hot-swapped—removed and installed while the server is powered-on. However, to prevent
potential damage to the transceiver or the fiber-optic cable, disconnect the cable from the transceiver before hot-swapping
it.
CAUTION:CAUTION:
Do not remove and install transceivers more often than is necessary. Doing so can shorten the useful life of the transceiver.
IMPORTANT:IMPORTANT:
When you replace a transceiver with another of a different type, the server might retain selected port-specific configuration
settings that were configured for the replaced transceiver. Be sure to validate or reconfigure port settings as required.
Installing a transceiverInstalling a transceiver
