HP ProLiant DL560 Gen11 - 8 SFF x1 SAS drive controller cabling: Type-p controller in the primary riser

Cable part numberCable part number ColorColor FromFrom ToTo
P48964-001 Orange Box 3 ports 1–2 Type-o storage controller port 1
in Slot 14
Blue Box 3 ports 3–4 Type-o storage controller port 2
in Slot 14
Option kit: P61603-B21
8 SFF x1 SAS drive controller cabling: Type-p controller in the primary riser8 SFF x1 SAS drive controller cabling: Type-p controller in the primary riser
1
1
HPE ProLiant DL560 Gen11 Server User Guide 205
