ItemItem LEDLED StateState DefinitionDefinition
1 Fault/Locate Solid amber This drive has failed, is unsupported, or is invalid.
Solid blue The drive is operating normally and being identified by a
management application.
Flashing amber/blue (1
flash per second)
The drive has failed, or a predictive failure alert has been received
for this drive. The drive has also been identified by a management
application.
Flashing amber (1 flash
per second)
A predictive failure alert has been received for this drive. Replace
the drive as soon as possible.
Off The drive is operating normally and not being identified by a
management application.
2 Online/Activity Solid green The drive is online and has no activity.
Flashing green (4
flashes per second)
The drive is operating normally and has activity.
Off No power present
Drive bay numberingDrive bay numbering
CAUTION:CAUTION:
When a server is purchased without any drive installed, some drive bays might be empty while other drive bays might be
populated with drive blanks. To maintain proper system cooling, do not operate the server without a drive or a drive blank
installed.
SubtopicsSubtopics
SFF drive bay numberingSFF drive bay numbering
E3.S drive bay numberingE3.S drive bay numbering
SFF drive bay numberingSFF drive bay numbering
The following drive backplane options are supported in SFF drive configurations:
2 SFF stacked drive backplanes:
24G x4 U.3 NVMe / SAS UBM3 BC
24G x4 U.3 NVMe / SAS UBM6 BC
8 SFF drive backplanes:
8 SFF 24G x1 U.3 NVMe / SAS UBM3 BC
8 SFF 24G x1 U.3 NVMe / SAS UBM6 BC
8 SFF 24G x4 U.3 NVMe / SAS UBM3 BC
8 SFF 24G x4 U.3 NVMe / SAS UBM6 BC
For more information on the drive backplane description, see Drive backplane naming.
16 SFF + 2 SFF drive bay numbering16 SFF + 2 SFF drive bay numbering
