Storage controller cable
14. Install the fan cage.
15. Do one of the following:
Install the air baffle .
Install the processor mezzanine tray .
16. Install the access panel .
17. Installing the server into the rack .
18. Connect all peripheral cables to the server.
19. Connect each power cord to the power source.
20. Connect each power cord to the server.
21. Power up the server .
22. If removed, install the front bezel .
ResultsResults
The installation is complete.
Installing the 2 SFF stacked drive cageInstalling the 2 SFF stacked drive cage
PrerequisitesPrerequisites
Before you perform this procedure, make sure that you have a T-10 Torx screwdriver available.
About this taskAbout this task
The 2 SFF stacked drive cage in the universal media bay supports SAS, SATA, and U.3 PCIe4 NVMe drives .
CAUTION:CAUTION:
A discharge of static electricity from a finger or other conductor might damage system boards or other static-sensitive
devices. To prevent damage, observe antistatic precautions.
CAUTION:CAUTION: To prevent improper cooling and thermal damage, do not operate the server unless all bays are populated with
either a component or a blank.
ProcedureProcedure
Installing the 2 SFF stacked drive cage in the universal media bayInstalling the 2 SFF stacked drive cage in the universal media bay
1. Install the grommets onto the underside of the stacked drive cage.
