HP ProLiant DL560 Gen11 - Heatsink and processor socket components

The arrow points to the front of the server.
Heatsink and processor socket componentsHeatsink and processor socket components
A standard heatsink is shown, your heatsink might look different.
ItemItem DescriptionDescription
1 Processor-heatsink module
2 Anti-tilt wires
3 Processor carrier release tabs
4 Bolster plate guide posts
5 Bolster plate
6 Heatsink screws
This module consists of the heatsink attached to the processor that is already secured in its carrier.
Liquid cooling optionsLiquid cooling options
1
1
HPE ProLiant DL560 Gen11 Server User Guide 20
