HP ProLiant DL560 Gen11 - PCIe5 slot description

To Next Page

To Previous Page

ItemItem DescriptionDescription

1 Storage controller backup power connectors

2 PCIe5 x16 (16, 8, 4, 1) slots

3 LP SlimSAS connector 1

4 LP SlimSAS connector 2

PCIe5 slot descriptionPCIe5 slot description

HPE ProLiant DL560 Gen11 Server User Guide 24
