HP ProLiant DL560 Gen11 - 8 SFF x4 NVMe drive controller cabling: Type-o controller in Slot 15 and type-p controller in the secondary riser

Option kit: P55320-B21
SR932i-p controller in the secondary riser when the box 1 is the universal media bay
Cable part numberCable part number ColorColor FromFrom ToTo
P55362-001 Orange Box 2 port 1 Secondary type-p storage
controller port 1
Blue Box 2 port 2 Secondary type-p storage
controller port 2
Gold Box 2 port 3 Secondary type-p storage
controller port 3
Pink Box 2 port 4 Secondary type-p storage
controller port 4
Option kit: P55320-B21
8 SFF x4 NVMe drive controller cabling: Type-o controller in Slot 15 and type-p controller in the secondary riser8 SFF x4 NVMe drive controller cabling: Type-o controller in Slot 15 and type-p controller in the secondary riser
1
1
1
HPE ProLiant DL560 Gen11 Server User Guide 199
