14. Connect each power cord to the power source.
15. Connect each power cord to the server.
16. Power up the server .
17. To configure the memory settings:
a. From the boot screen, press F9F9 to access the UEFI System Utilities.
b. From the System Utilities screen, select System Configuration > BIOS/Platform Configuration (RBSU) > Memory Options.
ResultsResults
The installation is complete.
Riser board optionsRiser board options
The server supports two preinstalled PCIe riser cages that can be configured with different riser boards. Both primary and secondary riser
cages support installation of the following riser boards:
3-slot riser board with 2 x8 and 1 x16 connections
3-slot riser board with 3 x16 connections
SubtopicsSubtopics
Installing the riser boardInstalling the riser board
Installing the riser boardInstalling the riser board
PrerequisitesPrerequisites
Before you perform this procedure, make sure that you have a T-15 Torx screwdriver available.
About this taskAbout this task
CAUTION:CAUTION:
A discharge of static electricity from a finger or other conductor might damage system boards or other static-sensitive
devices. To prevent damage, observe antistatic precautions.
ProcedureProcedure
1. Power down the server.
2. If installed, open the cable management arm .
3. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
4. Disconnect all peripheral cables from the server.
5. Remove the server from the rack .
6. Place the server on a flat, level work surface.
7. Remove the access panel .
