ResultsResults
The installation is complete.
Processor heatsink assembly optionProcessor heatsink assembly option
SubtopicsSubtopics
Processor cautionsProcessor cautions
Installing the processor heatsink assemblyInstalling the processor heatsink assembly
Processor cautionsProcessor cautions
CAUTION:CAUTION: To avoid damage to the processor or system board, only authorized personnel should attempt to replace or
install the processor in this server.
CAUTION:CAUTION: To prevent possible server malfunction and damage to the equipment, multiprocessor configurations must
contain processors with the same part number.
CAUTION:CAUTION: The pins on the processor socket and on the processor are very fragile and easily damagedThe pins on the processor socket and on the processor are very fragile and easily damaged . To avoid component
damage, do not touch these pinsdo not touch these pins . Any damage to them might require replacing the system board and/or processor.
IMPORTANT:IMPORTANT: Processor socket 1 must be populated at all times or the server does not function.
IMPORTANT:IMPORTANT: If installing a processor with a faster speed, update the system ROM before installing the processor. To
download firmware, see Updating firmware or system ROM .
Installing the processor heatsink assemblyInstalling the processor heatsink assembly
PrerequisitesPrerequisites
Before you perform this procedure, make sure that you have the following items available:
T-30 Torx screwdriver
Processor option
About this taskAbout this task
This procedure only shows the installation steps for the standard and high performance heatsink options. In the liquid cooling configuration,
the liquid cooling options with the heatsinks are by default In the server.
ProcedureProcedure
1. Power down the server.
2. If installed, open the cable management arm .
3. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
4. Disconnect all peripheral cables from the server.
