5 Fabric Element MIB Objects
This section contains detailed information about the Fabric Element–Management Information Base
(FE-MIB) on the HP StorageWorks SN6000 and 8/20q Fibre Channel Switch.
Fibre Channel FE-MIB definitions
The textual substitutions in Table 31 are specific to the FE-MIB and can be used in place of primitive data
types.
Table 31 FE-MIB textual substitutions
Description Syntax
MilliSeconds Unsigned32
MicroSeconds Unsigned32
FcNameId OCTET STRING (SIZE (8))
FcAddressId OCTET STRING (SIZE (3))
FcRxDataFieldSize Integer32 (128..2112)
FcBbCredit Integer32 (0..32767)
FcphVersion Integer32 (0..255)
FcStackedConnMode INTEGER {
none(1)
transparent(2)
lockedDown(3)
}
FcCosCap BITS {
classF(0)
class1(1)
class2(2)
class3(3)
class4(4)
class5(5)
class6(6)
}
