HP StorageWorks 8/20q and SN6000 Fibre Channel Switch Simple Network Management Protocol Reference Guide 171
6 Private Enterprise MIB Objects
This section covers the implementation details for the Private (Enterprise-specific) Management Information
Base on the HP StorageWorks SN6000 and 8/20q Fibre Channel Switch.
Private Enterprise MIB definitions
This MIB replaces the fcFxPortPhystable module defined in FIBRE-CHANNEL-FE-MIB, and defines
volatile control objects for ports in an SN6000 or 8/20q Fibre Channel Switch. If the switch gets reset,
these values revert back to the default values in the configuration file.
f c Q x Po r t P h y s A d m i n S t a t u s (1. 3 . 6 .1. 4 .1.16 6 3 .1. 3 .10 .1.1. 3 )
The desired state of the FxPort. A management station may place the FxPort in a desired state by setting
this object accordingly. The testing(3) state indicates that no operational frames can be passed. When
a fabric element initializes, all FxPorts start with fcQxPortPhysAdminStatus in the o?fline(2)
state. As the result of either explicit management action or per configuration information accessible by the
fabric element, fcQxPortPhysAdminStatus is then changed to either the online(1) or
testing(3) states, or remains in the offline state.
Syntax
INTEGER {
online(1)–Place port online
offline(2)–Take port offline
testing(3)–Initiate test procedures
}
Access
Read-Read-write
Status
Current
Return value
See Table 37 for fcQxPortPhysAdminStatus read values.
See Table 38 for fcQxPortPhysAdminStatus write values.
Table 37 fcQxPortPhysAdminStatus read values
Port Value
Online online(1)
Offline offline(2)
Diagnostics testing(3)
Down offline(2)
Table 38 fcQxPortPhysAdminStatus write values
Port Value
Online online(1)
Offline offline(2)
Diagnostics testing(3)
