HP StorageWorks 8/20q Reference Guide

90 Fibre Alliance MIB Objects
Return value
If F or FL, returns 0x0c (Class 2, and Class 3), else returns 0x0d (Class f, Class 2,
and Class 3).
connUnitPortState (1.3.6.1.3.94.1.10.1.6)
The user selected state of the port hardware
Syntax
INTEGER {
unknown(1),
online(2)–Available for meaningful work
offline(3)–Not available for meaningful work
bypassed(4)–No longer used (4/12/00)
diagnostics(5)
}
Access
Read-only
Status
Mandatory
Return value
See Table 21 for connUnitPortState return values.
connUnitPortStatus (1.3.6.1.3.94.1.10.1.7)
An overall protocol status for the port. If this value of connUnitPortState is not online, then this is
reported Unknown.
Syntax
INTEGER {
unknown(1)
unused(2)–Device cannot report this status
ready(3)–FCAL Loop or FCPH link reset protocol; initialization complete
warning(4)–Do not use (4/12/00)
failure(5)–Do not use (4/12/00)
notparticipating(6)–Loop is not participating and does not have a loop address
initializing(7)–Protocol is proceeding
bypass(8)–Do not use (4/12/00)
ols(9)–FCP offline status
other(10)–Status not described above
Table 21 ConnUnitPortState return values
Port value Return value
Online online(2)
Offline offline(3)
Downed offline(3)
Diagnostics diagnostics(5)
Other unknown(1)
