HP StorageWorks 8/20q

92 Fibre Alliance MIB Objects
connUnitPortModuleType (1.3.6.1.3.94.1.10.1.9)
The module type of the port connector
Syntax
INTEGER {
unknown(1)
other(2)
gbic(3)
embedded(4)–Fixed (oneXnine)
glm(5)
gbicSerialId(6)
gbicNoSerialId(7)
gbicNotInstalled(8)
smallFormFactor(9)–Generally a small form factor connector.
}
Access
Read-only
Status
Mandatory
Return value
See Table 23 for connUnitPortModuleType return values.
connUnitPortWwn (1.3.6.1.3.94.1.10.1.10)
The WWN of the port, if applicable; otherwise returns all zeros.
Syntax
FcGlobalId
Access
Read-only
Status
Mandatory
Return value
Returns the port WWN followed by 8 bytes of zeros. For example, the return value for port #2 would
be 20 02 00 C0 DD 00 71 C9 00 00 00 00 00 00 00 00, and the return value for port #2
would be 20 0E 00 C0 DD 00 71 C9 00 00 00 00 00 00 00 00. If a port is configured as
a donor, the return value is 0.
connUnitPortFCId (1.3.6.1.3.94.1.10.1.11)
This is the assigned Fibre Channel ID of this port. This value is expected to be a Big Endian value of 24
bits. If this is a loop, then it is the AL_PA that is connected. If this is an E_Port, then it only contains the
domain ID left-justified, zero-filled. If this port does not have a Fibre Channel address, returns all bits set to
1.
Table 23 connUnitPortModuleType return values
Type Return value
1/2/4/8 Gb/s Ports smallFormFactor(9)
10/20 Gb/s Ports Other (2)
