172 Private Enterprise MIB Objects
f c Q x Po r t P h y s O p e r S t a t u s (1. 3 . 6 .1. 4 .1.16 6 3.1. 3 .10 .1.1. 4 )
The current operational status of the FxPort. The testing(3) status indicates that no operational
frames can be passed.
• If fcQxPortPhysAdminStatus is offline(2), then fcQxPortPhysOperStatus should be
offline(2).
• If fcQxPortPhysAdminStatus is changed to online(1), then fcQxPortPhysOperStatus
should change to online(1).
• If the FxPort is ready to accept Fabric Login request from the attached NxPort, it should
proceed and remain in the linkFailure(4) state only if there is a fault that prevents it from going to
the online(1) state.
Syntax
INTEGER {
online(1)–Login may proceed
offline(2)–Login cannot proceed
testing(3)–Port is under test
linkFailure(4)–Failure after online/testing
}
Access
Read-only
Status
Current
Return value
See Table 39 for fcQxPortPhysOperStatus return values.
Related traps
The traps described below contain the trap information being sent from the agent to the manager.
qlSB2PortLinkDown (qLogicExperimental 0 10)
A linkDown trap signifies that the SNMP entity, acting in an agent role, has detected that the
fcQxPortPhysOperStatus object for one of its communication links has left the online state and
transitioned to some other state. The current state is indicated by the included value of
fcQxPortPhysOperStatus.
Variables:
{ fcQxPortPhysAdminStatus, fcQxPortPhysOperStatus }
qlSB2PortLinkUp (qLogicExperimental 0 11)
A linkUp trap signifies that the SNMP entity, acting in an agent role, has detected that the
fcQxPortPhysOperStatus object for one of its communication links has entered the online state from
some other state. The current state is indicated by the included value of fcQxPortPhysOperStatus.
Table 39 fcFxPortPHysOperStatus return values
Status Return value
Online online(1)
Offline offline(2)
Diagnostics testing(3)
Down linkfailure(4)
