125
Table 22 Command output
Field Description
PoE status
PoE status:
• Enabled.
• Disabled.
Power Priority
Power supply priority of the PI:
• Critical (highest).
• High.
• Low.
Oper
Operating status of a PI:
• Off—PoE is disabled.
• On—Power is being supplied to the PI correctly.
• Power-lack—Remaining guaranteed power is insufficient for a
critical PI.
• Power-deny—The
PSE refuses to supply power. The power
required by the PD is higher than the configured power.
• Power-itself—The PD is using another power supply.
• Power-limit—The PSE is supplying power to the PD based on
the configured power though the PD requires more power than
the configured power.
IEEE Class
PD power class: 0, 1, 2, 3, or 4.
If the PSE does not support PD classification, this field displays a
hyphen (-).
Detection Status
Power detection status of a PI:
• Disabled—The PoE function is disabled.
• Searching—The PI is searching for the PD.
• Delivering power—The PI is supplying power to the PD.
• Fault—A fault occurred during the test.
• Test—The PI is undergoing a test.
• Other fault—A fault has caused the PSE to enter the idle status.
• PD disconnected—The PD is disconnected.
Power Mode
Power transmission mode of a PI:
• Signal—Power is being supplied over signal cables.
• Spare—Power is being supplied over spare cables.
Current Power
Current power of a PI, including PD consumption power and
transmission loss.
Typical transmission loss is within 1 watt.
Average Power Average power of a PI.
Peak Power Peak power of a PI.
Max Power Maximum power of a PI.
Electric Current Current of a PI.
Voltage Voltage of a PI.
PD Description Type and location description for the PD connected to the PI.
# Display power supplying information for all PIs.
<Sysname> display poe interface
Interface PoE Priority CurPower Oper IEEE Detection
