126
(W) Class Status
GE1/0/1 Enabled Low 4.4 On 1 Delivering Power
GE1/0/2 Enabled Critical 0.0 On - Disabled
GE1/0/3 Enabled Low 0.0 On - Disabled
GE1/0/4 Enabled Critical 0.0 On - Searching
GE1/0/5 Enabled Low 4.0 On 2 Delivering Power
GE1/0/6 Enabled Low 0.0 On - Disabled
GE1/0/7 Disabled Low 0.0 Off - Fault
--- On State Ports: 2; Used: 8.4(W); Remaining: 171.6(W) ---
Table 23 Command output
Field Description
Interface Interface name of a PI.
PoE
PoE status:
• Enabled.
• Disabled.
Priority
Power priority of a PI:
• Critical (highest).
• High.
• Low.
CurPower Current power of a PI.
Oper
Operating status of a PI:
• Off—PoE is disabled.
• On—Power is being supplied to the PI correctly.
• Power-lack—Remaining guaranteed power is insufficient for a
critical PI.
• Power-deny—The
PSE refuses to supply power. The power
required by the PD is higher than the configured power.
• Power-itself—The PD is using another power supply.
• Power-limit—The PSE is supplying power to the PD based on
the configured power though the PD requires more power than
the configured power.
IEEE Class PD power class: 0, 1, 2, 3, or 4.
Detection Status
Power detection status of a PI:
• Disabled—PoE function is disabled.
• Searching—The PI is searching for the PD.
• Delivering Power—The PI is supplying power for the PD.
• Fault—A fault occurred during the test.
• Test—The PI is undergoing a test.
• Other fault—A fault has caused the PSE to enter the idle status.
• PD disconnected—The PD is disconnected.
On State Ports Number of PIs that are supplying power.
Used Power consumed by the current PI.
Remaining Total remaining power of the system.
