HPE ProLiant ML350 Gen11

To Next Page

To Previous Page

ItemItem DescriptionDescription

1 Storage controller backup power connectors

2 PCIe5 x16 (8, 4, 1) slots

PCIe5 2 x16 riser componentsPCIe5 2 x16 riser components

ItemItem DescriptionDescription

1 GPU auxiliary power connectors

2 Storage controller backup power connectors

3 PCIe5 x16 (16, 8, 4, 1) slots

Tertiary riser componentsTertiary riser components

HPE ProLiant ML350 Gen11 Server Maintenance and Service Guide 192
