Cable part numberCable part number ColorColor FromFrom ToTo

P43735-001 Orange CPU 1 MCIO port 1 Slot 15 OCP port 1

Option kit: P47231-B21

Serial port cablingSerial port cabling

HPE ProLiant ML350 Gen11 Server Maintenance and Service Guide 230
