HPE ProLiant ML350 Gen11

To Next Page

To Previous Page

Cable part numberCable part number ColorColor FromFrom ToTo

P58422-001 Orange Accelerator power connector GPU auxiliary power connector

on the PCIe5 2 x16 riser

Option kit: P47221-B21

Fan cablingFan cabling

Internal fans 1–8Internal fans 1–8

HPE ProLiant ML350 Gen11 Server Maintenance and Service Guide 227
